Электрический мини-четырехколесный автомобиль

Электрический мини-четырехколесный автомобиль

Вид оплаты: T/T
Инкотермс: FOB
Количество минимального заказа: 1 Piece/Pieces
транспорт: Ocean

Свяжитесь с нами

Получить цену



PRODUCT ATTRIBUTES



Overview

Атрибуты продукта

Модель: JINGANG-H1

марка: Цзинган

Origin: Китай

Тонкость: Новый

Происхождение: Китай

Overview

Возможности поставки и дополнительная информация

транспорт: Ocean

Место происхождения: Китай

Вид оплаты: T/T

Инкотермс: FOB

Упаковка и доставка

Продажа единиц жилья:	Piece/Pieces

Описание продукта

project	Parameter Item	H1Standard Model	H1Luxury Model
project	Parameter Item	H1Standard Model	H1Luxury Model
Vehicle dimensions and weight	Length × Width × Height (mm)	3210×1480×1545	3210×1480×1545
	wheel base (mm)	2140	2140
	tread (mm)	1220/1210	1220/1210
	curb weight （kg）	525	525
Electromechanical Power Parameters	motor rated output power (kW)	4	6
	Maximum output torque of the motor (N·m)	60	75
	Motor Type	Permanent Magnet Synchronous	Permanent Magnet Synchronous
	Battery Type	lithium iron phosphate	lithium iron phosphate
	Battery capacity	1	1
	system voltage V	72V	72V
	quantity of electricity kWh	7.2	9
	Charger model	7215	72-25
	Charging and heating auxiliary device	--	--
drive system, transmission agent	Driving Method	rear-wheel drive	rear-wheel drive
drive system, transmission agent	Single-span bridge (speed ratio 10:1)	●	●
Driving/Steering System	Suspension system (front/rear)	McFerson independent suspension / Five-link non-independent suspension	McFerson independent suspension / Five-link non-independent suspension
	steering system	Gear-rack steering system	Gear-rack steering system
	tyre size	145/70 R12	155/70 R12
brake assembly,brake system,braking system,retrosystem	brake assembly,brake system,braking system,retrosystem	Front disc and rear drum hydraulic dual-circuit braking system	Front disc and rear drum hydraulic dual-circuit braking system
Vehicle Performance Parameters	Minimum ground clearance (mm)	180	180
	Minimum turning diameter (m)	8	8
	Maximum speed (km/h) (displayed)	45	45
	Isokinetic range (km) (Economy/Sport)	130/115	130/115
	Maximum gradient of a single-span bridge	20%	20%
Operation Configuration	vacuum booster	●	●
	power-assisted steering
	Economic/Sports Dual Mode
seat	Simulated leather seat	○
	The driver's seat features four-way manual adjustment.	●
	The passenger seat features four-way manual adjustment.
	The rear seats are foldable.
interior collocation	Multimedia (with USB port)
	2 speakers
	reading lights
	back up power,back-up power
	Manual anti-glare interior rearview mirror
	Front door electric glass lift
	Chromium-plated door inner handle	○	○
External Configuration	Rearview camera	●	●
	LED transparent halogen integrated front headlight assembly
	LED rear combination tail lights
	Aluminum wheel	○
air-conditioning, air conditioner	warm air blower	○	○
Safety Equipment	Front three-point seat belt	●	●
	Backdoor child safety lock
	Remote control for the central door lock
	Emergency rescue toolkit (vehicle-mounted tool)
	High-level brake light
pigment, dyestuff
remarks, comments on a form, remark	"●" indicates standard equipment, "○" indicates optional equipment, and "--" indicates unavailable equipment.
